˙ Wonderful sound quality for music instruments studio /stage recording
˙ Changeable design for electric guitar plug or winds microphone
˙ Easy to use and the plug can be rotated up to 90°.
˙ FHSS hopping technique with 4 preset hopping frequencies
˙ Made in Taiwan with CE, FCC and RSS-123 ISSUE 2/3 certificate
˙ One-touch ACT syncs and clear indicator for easy use
˙ High-effect rechargeable lithium battery
˙ High-effect rechargeable lithium battery
Complete System
-
Model No.
GHD-24G / GHD-24GB
-
Frequency Rang
ISM 2400–2483.5 MHz
-
Audio Sampling
24-bit / 44.1 kHz
-
Latency
< 4.0 ms
-
Frequency-hopping
4 preset hopping frequencies
-
Preset Frequency
12
-
Band width
83 MHz
-
Channel set-up
ACT-Sync
Receiver
-
Model No.
GHD-24MR
-
Frequency response
20-20KHz
-
Display
graphic OLED
-
Audio Output Adjustment
-10 ~ +20 dB
-
Frequency Stability
± 0.005%
-
Sensitivity
< -95 dBm
-
S/N ratio
> 115 dB(A)
-
THD
0.1%, @ 1 kHz
-
Output
balanced XLR & 6.3 mm
-
Power supply
12 - 18V DC / 300 mA
-
Size
210*180*40 mm
-
Weight
750 g
Transmitter
-
Model No.
GHD-2400GT / GHD-2400BT
-
Frequency response
20-20KHz / 65-20KHz
-
RF Output Power
2 / 10mW switchable
-
Max. Audio Input
6.5 dBV
-
Current Consumption
138 mA
-
Battery Meter
4-level green / red LED display
-
Power supply
ICR 18500 lithium battery
-
Operating time
> 10h
-
Size
84*35*29mm
-
Weignt
61g
Winds Microphone
-
Model No.
GHD-WM-20
-
Frequency response
65-20KHz
-
Polar Pattern
Cardioid
-
Max. SPL
142 dB
-
Sensitivity
-52 dB
-
Size
10*197mm
-
Weignt
37g
Wireless system
